↗ eBPF/XDP on macOS with Apple container

Reproduction of eBPF/XDP Applications on macOS with Colima, Docker blogpost, with Apple's native container CLI in place of Colima + Docker, plus a custom kernel that restores the features Apple's stock VM kernel leaves out.

Host: Apple M4, macOS 27.0 (build 26A5406e), container 1.3.0, kernel 6.18.15 aarch64.

Verdict

1:1 parity with the blog, and then some. Build, load, attach and detach all happen inside Apple container. Everything is aarch64 — [build] rosetta is set to false in ~/.config/container/config.toml, so Rosetta is not merely unused, it is unavailable to the builder VM.

With the custom kernel in kernel/ the environment additionally supports the things the blog never gets to: CO-RE, kprobes/tracepoints/fentry, BPF LSM, AF_XDP and the JIT.

Two kernels

	stock (vmlinux-6.18.15-186)	custom (kernel/vmlinux-ebpf-6.18.15)
XDP generic on eth0	yes	yes
XDP native + bpf_link on veth	yes	yes
XDP native on eth0	no (see below)	no (host-side, not fixable in the guest)
tc/cgroup/socket/sk_msg progs	yes	yes
kprobe / tracepoint / fentry / LSM	no	yes
BTF (/sys/kernel/btf/vmlinux) → CO-RE	no	yes (4.5 MB, 110k-line vmlinux.h)
AF_XDP (xskmap, XDP_SOCKETS)	no	yes (native mode on veth)
JIT	no (xlated 16B not jited)	yes (xlated 16B jited 56B)
tracefs / bpf_printk	no	yes

Native XDP on eth0 is impossible in both: Apple's vmnet virtio-net advertises rx-gro-hw: on [fixed], so the driver refuses with "Can't set XDP while host is implementing GRO_HW/CSUM". bpf_link XDP attach also fails on that device. Use xdpgeneric on eth0, or a veth pair for native-mode work — src/main.go falls back automatically (bpf_link → netlink native → netlink generic).

Layout

Containerfile arm64 builder/runner image (clang, llvm, libbpf, bpftool, Go 1.25)
src/ the blog's XDP program + Go loader (bpf2go)
tracing/ CO-RE kprobe on do_execveat_common -> ring buffer
afxdp/ libxdp UMEM + xsk_socket__create bound to veth0
kernel/build-kernel.sh builds the eBPF-enabled arm64 kernel inside a container

Usage

make image # arm64 builder image
make build # clang -target bpf + bpf2go + go build
make demo # XDP attach on veth0 (run `make build` first; stock kernel is enough)
make kernel # build kernel/vmlinux-ebpf-6.18.15 (~5 min on M4, 8 cores)
make tracing # CO-RE kprobe demo (requires custom kernel)
make afxdp # AF_XDP socket demo (requires custom kernel)
make probe # capability dump; KERNEL=... to compare kernels

KERNEL=kernel/vmlinux-ebpf-6.18.15 is passed via container run -k, per container — the system default kernel is left untouched. To make it the default: container system kernel set --arch arm64 --binary $PWD/kernel/vmlinux-ebpf-6.18.15 --force (verified flag syntax; --recommended restores Apple's default). To exercise a target against the stock kernel instead, pass a non-existent path: make probe KERNEL=none.

--cap-add ALL is required; each container is root in its own micro-VM, so there is no privileged flag and none is needed.

Kernel build notes

• Base config is the running kernel's own /proc/config.gz, so the build only adds features. Enabled: DEBUG_INFO_BTF (+DWARF5), KPROBES, KPROBE_EVENTS, UPROBES, FTRACE, BPF_EVENTS, FPROBE, BPF_JIT (+default-on), BPF_LSM, XDP_SOCKETS (+diag), NET_CLS_BPF, NET_ACT_BPF, DEBUG_FS.
• The build runs in a container volume (kernelbuild), not on a virtiofs mount of the host: macOS APFS is case-insensitive and the Linux source has case-colliding filenames, so extracting onto the host fails with Permission denied. Only arch/arm64/boot/Image is copied back.
• scripts/config --enable takes one symbol per invocation; passing a list silently prints usage and (under set -e) kills the build.
• Output must be arch/arm64/boot/Image (raw ARM64 boot Image) — that is the format container expects, matching Apple's own kernel file.

Differences from the blogpost

• Colima + Docker → container build / container run; each container is its own lightweight VM.
• The blog cross-compiles the loader to linux/amd64 as a deploy artifact that cannot run on the host. Here the loader is built arm64 and actually executed and attached locally; GOARCH=amd64 go build still produces the deploy binary.
• bpf2go -type event needs the struct referenced from a dummy global (const struct event *unused_event), otherwise clang drops it from BTF.

Host config changes made

• ~/.config/container/config.toml: removed a stale [kernel] block pointing at a Kata tarball — container 1.3.0 rejects it with kernel.digest is required when kernel.url is not the default URL and refuses to start. Set [build] rosetta = false. Backups: config.toml.bak.*.

Reference

• Reproduction of eBPF/XDP Applications on macOS with Colima, Docker
